SMC-600
SMARC 2.2 is a modular and flexible embedded computing platform designed to empower developers in building next-generation AI-driven edge devices with ease. Available in the SMC-600 (QCS6490) configuration, it offers high performance and scalability, enabling seamless integration for a variety of applications. With its versatile architecture, SMARC 2.2 simplifies the development process while delivering the power and efficiency needed to support advanced AI and edge computing solutions.
-
Powerful CPU & GPU: 8x Kryo 670 CPU (1.9 - 2.7 GHz) paired with Adreno 643 GPU for smooth processing and graphics rendering
-
Large Memory & Storage: 8 GB RAM and 128 GB internal storage for seamless multitasking and sufficient space for apps and media
-
Advanced Connectivity Options: Includes HDMI 2.0b FHD@30fps, Wi-Fi 6 (802.11ax), Bluetooth® 5.2, and multiple USB (3.0 & 2.0), LAN, and PCIe interfaces for versatile connectivity
-
Enhanced Camera & Display Support: Dual CSI camera interfaces and MIPI DSI x1 support for high-quality imaging and display output
-
Durable & Reliable Design: IP40 ingress protection, operating temperature range from -20°C to 70°C, and humidity tolerance of up to 95% RH, ideal for rugged environments
|
Processsor | |
|---|---|
|
SoC |
Qualcomm® QCS6490 Octa-Core @ 2.7 GHz |
|
Memory |
8 GBytes LPDDR5 |
|
Video | |
|
GPU |
Adreno GPU 643 |
|
HDMI |
HDMI 2.0b FHD@30fps |
| MIPI | DSI x 1 |
| Camera | CSI x 2 |
|
System Storage | |
|
SDIO |
4-bit x 1 |
| eMMC | 128 GBytes |
|
Audio | |
|
Audio |
I2S x 1 |
|
Ethernet | |
|
LAN |
GbE x 2 |
|
Wireless | |
|
Wi-Fi |
Wi-Fi 6 (802.11ax) |
| Bluetooth | Bluetooth® 5.2 |
|
Extension | |
|
USB |
USB 3.0 Host x 2, USB 2.0 Host x 2 |
|
UART |
4-wires x 2, 2-wires x 2 |
|
CAN |
CAN 2.0B x 1 |
| SPI | x 2 |
| I2S | x 1 (Audio Interface) |
| I2C | x 5 |
| GPIO | x 14 |
| PCIe | PCIe Gen3 x 2 |
| Power | |
| Input | 5Vdc +/- 5% |
| Environmental | |
| Operating Temperature | -20°C ~ 70°C |
| Humidity | 95% RH |
| Operating System | |
| Standard OS | Android/Linux |
All product specifications are subject to change without notice.
